ZED-F9P RTK receiver board with MultiBand antenna L1 L2 +LIS3MDL
  • ZED-F9P RTK receiver board with MultiBand antenna L1 L2 +LIS3MDL
  • ZED-F9P RTK receiver board with MultiBand antenna L1 L2 +LIS3MDL
  • EAN-4751046551778 (ZED-F9P High Precision GNSS receiver USB)

ZED-F9P RTK receiver board with MultiBand antenna L1, L2 and EMI + LIS3MDL with wire pad

ELT0177

ZED-F9P High Precision GNSS receiver USB, UART, with MultiBand antenna L1, L2 Base or Rover operation and EMI protection. LIS3MDL magnetometer. Designed with wire pads for wires soldering to board.>

VOLUME SALES PRICING

This product comes with 1 years worldwide warranty

249.99 €
Tax excluded
Quantity

100% secure payments
Total Rating Total Rating:

0 1 2 3 4
0/5 - 0 reviews

View ratings
0 1 2 3 4 0
0 1 2 3 0 0
0 1 2 0 1 0
0 1 0 1 2 0
0 0 1 2 3 0

  Add Review View Reviews View Reviews
  Security policy

Security policy

  Delivery policy

Delivery policy

  Return policy

Return policy

Description

ZED-F9P High Precision GNSS receiver module with USB, UART interfaces and Multi Band L1, L2 antenna. Base or Rover operation. Multi-band receiver delivers centimeter-level accuracy in seconds. Build-in EMI protection and LIS3MDL Magnetometer. Designed with wire pads for directly soldering to boards.

The ZED-F9P positioning module features the new u-blox F9receiver platform, which provides multi-band GNSS to high volume industrial applications in a compact form factor. ZED-F9P is a multi-band GNSS module with integrated u-blox multi-band RTK technology for centimeter-level accuracy. The module enables precise navigation and automation of moving industrial machinery by means of a small, surface mounted module.

The ZED-F9P module is designed for easy integration and low design-in costs with minimal e-BOM. It is well-suited for mass market adoption, thanks to its small package size, light weight, and small power consumption. ZED-F9P ensures the security of positioning and navigation information by using secure interfaces and advanced jamming and spoofing detection technologies.

ZED-F9P offers support for a range of correction services allowing each application to optimize performance according to the application’s individual need. ZED-F9P comes with built-in support for standard RTCM corrections, supporting centimeter-level navigation from local base stations or from virtual reference stations (VRS) in a Network RTK setup. The module can be upgraded to support future SSR-type correction services suitable for mass market penetration.

ZED-F9P receiver board features:

  • On-board Ultra low noise 3.3V voltage regulator with noise 2nV/Hz
  • USB, I2C (SDA, SCL) for magnetometer and UART (Tx, Rx) interface
  • MultiBand L1, L2 antenna
  • LIS3MDL I2C magnetometer
  • u-center u-blox Evaluation Software
  • Extensive visualization and evaluation features
  • Time pulse LED, GEO LED, RTK LED
  • Backup supercapacitor
  • Dimensions: 70x70 mm
  • Weight: 56 gr.
  • Fully assembled and ready to use
  • Wire pads for soldering to boards
  • EMI protection

ZED-F9P Features:

Receiver type:

  • 184-channel u-blox F9 engine
  • GPS L1C/A L2C,
  • GLO L1OF L2OF,
  • GAL E1B/C E5b,
  • BDS B1I B2I,
  • QZSS L1C/A L2C

Nav. update rate:

  • RTK up to 20 Hz1

Position accuracy:

  • RTK 0.01 m + 1 ppm CEP
  • SPARTN Horizontal pos. accuracy – 0.06m, vert -0.12m

Convergence time:

  • RTK <10 sec
  • SPARTN Convergence time - <45sec
  • Aided starts 2 s
  • Reacquisition 2 s

Sensitivity:

  • Tracking & Nav –167
  • Cold starts –148 dBm
  • Hot starts –157 dBm
  • Reacquisition –160 dBm

  • AssistNow GNSS Online
  • OMA SUPL & 3GPP compliant
  • TCXO Oscillator
  • Built-In RTC crystal
  • Active CW detection and removal
  • Active and passive antennas Supported
  • Flash Memory

Board can be used for a Base or Rover operation mode!

Product Details
ELT0177
4751046551778
ELT0177
259 Items
