NEO-M9N four GNSS Smart Antenna module with USB C and SMA antenna connectors in IP54 black plastic case for your UAV systems, Robots, RC, FPV or other projects. Ultra small and light. Designed to use together with recommended Helix antenna.
The NEO-M9N Smart Antenna module makes evaluating the high performance of the u-blox 9 positioning engine simple. With a built-in USB interface for both power supply and high-speed data transfer, the need for an external power supply is eliminated. The NEO-M9N Smart Antenna module is very compact, and it’s user-friendly interface and power supply options make it ideally suited for use in laboratories, vehicles and outdoor locations. Furthermore, the NEO-M9N breakout board can be used with a PDA or a notebook PC, making it the perfect companion through all stages of design-in projects. It’s a fully assembled, tested and sealed module for the NEO-M9N with SMA antenna connectors. It offer IP54 environment protection with recommended Helix antenna installed.
NEO-M9N Smart Antenna module features:
- 92-channel u-blox M9 engine GPS L1 C/A, QZSS L1 C/A/S, GLONASS L10F BeiDou B1I, Galileo E1B/C SBAS L1 C/A: WAAS, EGNOS, MSAS, GAGANv
- SuperSense Indoor GPS, -167dBm
- On-board low noise 3.3V voltage regulator
- USB C waterproof connector
- SMA antenna connector
- u-center ublox Evaluation Software
- Extensive visualization and evaluation features
- Supports AssistNow Online and AssistNow Offline A-GPS services
- Time pulse LED, Power LED
- Flash memory for firmware upgrade and settings inside in the module (can save setings without battery)
- Supercapacitor for HOT module start
- Dimensions: 40x12 mm
- Weight: 15 gr.
- Fully assembled, sealed and ready to use
- Magnetic mount with waterproof 3M double sided tape
- Waterproof 3M double sided tape for mounting
This board sells without antenna or with selected Helix antenna!
