NEO-M9N four GNSS receiver with SMA antenna connectors for your UAV systems, Robots, RC, FPV or other projects. Ultra small and light. 7075 Alluminium IP67 case.
The NEO-M9N USB C receiver makes evaluating the high performance of the u-blox 9 positioning engine simple. With a built-in USB interface for both power supply and high-speed data transfer, the need for an external power supply is eliminated. The NEO-M9N receiverd is very compact, and it’s user-friendly interface and power supply options make it ideally suited for use in laboratories, vehicles and outdoor locations.
Furthermore, the NEO-M9N receiver can be used with a Tablet or a notebook PC, making it the perfect companion through all stages of design-in projects. It’s a fully assembled and tested receiver NEO-M9N with SMA antenna connectors.
NEO-M9N USB dongle features:
- 92-channel u-blox M9 engine GPS L1 C/A, QZSS L1 C/A/S, GLONASS L10F BeiDou B1I, Galileo E1B/C SBAS L1 C/A: WAAS, EGNOS, MSAS, GAGAN
- SuperSense Indoor GPS, -167dBm
- On-board low noise 3.3V voltage regulator and RF filter for noise blocking
- USB interface type C connector
- Support active antenna
- SMA antenna connectors
- Power LED
- Time pulse LED
- Supports AssistNow Online and AssistNow Offline A-GPS services
- Flash memory for firmware upgrade and settings inside in the module (can save setings without battery)
- Can be easy mounted in your case by double sided tape
- Supercapacitor for HOT module start
- Dimensions without connectors: 40x30x18 mm
- Weight: 43 gr.
- 7075 T6 Aluminium case with IP 67 protection
- Fully assembled and ready to use
- NEO-M9N Product Summary
- NEO-M9N Data Sheet
- NEO-M9N Integration Manual
- u-blox M9 SPG 4.00 firmware
