NEO-M8T TIME & RAW GPS GNSS BeiDou + LIS3MDL Triple Band 35mm ANT

ELT0080

NEO-M8T TIME & RAW GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS receiver + LIS3MDL Compass

VOLUME SALES PRICING

This product comes with 1 years worldwide warranty

74.99 €
Tax excluded
Quantity

100% secure payments
Total Rating Total Rating:

0 1 2 3 4
0/5 - 0 reviews

View ratings
0 1 2 3 4 0
0 1 2 3 0 0
0 1 2 0 1 0
0 1 0 1 2 0
0 0 1 2 3 0

  Add Review View Reviews View Reviews
  Security policy

Security policy

  Delivery policy

Delivery policy

  Return policy

Return policy

Description

NEO-M8T TIME & RAW GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS receiver + LIS3MDL Compass, Triple band antenna

The NEO-M8T Evaluation board makes evaluating the high performance of the u-blox 8 positioning engine simple. With a built-in USB interface for both power supply and high-speed data transfer, the need for an external power supply is eliminated. The NEO-M8T Breakout board is very compact, and it’s user-friendly interface and power supply options make it ideally suited for use in laboratories, vehicles and outdoor locations. Furthermore, the NEO-M8T breakout board can be used with a PDA or a notebook PC, making it the perfect companion through all stages of design-in projects. It’s a fully assembled and tested PCB for the u-blox NEO-M8T with Compass

NEO-M8T breakout board features:

  • 72-channel u-blox M8 engine GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 SBAS L1 C/A: WAAS, EGNOS, MSAS Galileo-ready E1B/C (NEO-M8T)
  • SuperSense Indoor GPS, -167dBm
  • On-board low noise 3.3V voltage regulator and RF filter for noise blocking
  • USB, I2C (SDA, SCL)(for LIS3MDL) and UART (Tx, Rx)
  • Triple band GPS, GLONASS, BeiDou antenna
  • u-center ublox Evaluation Software
  • Extensive visualization and evaluation features
  • Supports AssistNow Online and AssistNow Offline A-GPS services
  • Time pulse LED
  • Flash memory for firmware upgrade and settings inside in the module (can save setings without battery)
  • Supercapacitor for HOT module start
  • Build-in LIS3MDL Compass
  • Dimensions: 50x50 mm; hole distance 45x45mm
  • Weight: 29 gr.
  • Fully assembled and ready to use

NEO-M8T features:

  • 72-channel u-blox M8 engine GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 SBAS L1 C/A: WAAS, EGNOS, MSAS Galileo-ready E1B/C (subject to Firmware upgrade)
  • Nav. update rate Concurrent GNSS: up to 2 Hz
  • Position accuracy 2.5 m CEP (Autonomous)
  • Acquisition GPS, GLONASS GPS, BeiDou
  • Cold starts: 26 s 27 s
  • Aided cold starts: 2 s 3 s
  • Sensitivity Tracking & Nav: –167 dBm –165 dBm
  • Cold starts (aided): –157 dBm –151 dBm
  • (autonomous): –148 dBm –148 dBm
  • Reacquisition: –160 dBm –160 dBm
  • Assistance AssistNow GNSS Online
  • AssistNow GNSS Offline (up to 35 days)
  • AssistNow Autonomous (up to 6 days)
  • OMA SUPL & 3GPP compliant
  • TCXO Oscillator
  • Built-In RTC crystal
  • Extra LNA for passive antenna
  • Anti jamming Active CW detection and removal.
  • On-board SAW band pass filter
  • Internal SQI Flash for Firmware update
  • Active and passive Supported antennas

NEO-M8T / LEA-M8T Product Summary

NEO-LEA-M8T Data Sheet

NEO-8Q / NEO-M8 FW3 Hardware Integration Manual

Product Details
ELT0080
4751046550801
ELT0080
178 Items
New
