mosaic-G5 P6 RTK with LoRa technology GNSS receiver board
mosaic-G5 P6 RTK with LoRa technology GNSS receiver board
B2B Wholesale pricing available
Register as a wholesale buyer to access special pricing and bulk discounts on many products.
Get B2B ConsultationTax excluded
mosaic-G5 P6 all-constellation multi-frequency top-performance high precision RTK GNSS receiver with LoRa RTK corrections receiver.
mosaic-G5 P6 RTK GNSS with integrated LoRa delivers reliable centimeter-level accuracy, making it ideal for surveying, agriculture, construction, drones, and multi-drone swarms without relying on mobile networks. It tracks all Global Navigation Satellite System (GNSS) constellations and supports all current and future signals.
Achieve uncompromising accuracy for your most demanding projects with centimeter-level advanced RTK positioning and Galileo HAS corrections. Built for maximum responsiveness, the system delivers raw measurements with ultra-low latency and an exceptional 100 Hz update rate, while the dual-antenna configuration guarantees highly reliable heading data. To secure your operations in challenging RF environments, the receiver integrates AIM+ Premium—part of the advanced GNSS+ algorithm suite—providing superior protection against signal jamming and spoofing. All of this robust performance is delivered with industry-leading ultra-low power consumption, maximizing your equipment's autonomy in the field.
Available in stock (>10 pcs)
1 Year Limited Warranty
14-day hassle-free returns
Lifetime technical support
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Couldn't load pickup availability
Product Features
Product Features
An RTK GNSS receiver with integrated LoRa is ideal for applications where centimeter-level accuracy is required in areas with limited or no internet access. The LoRa link provides a low-power, long-range channel for receiving RTCM corrections directly from a local base station.
This makes it especially suitable for:
- Surveying and construction – reliable corrections without mobile networks.
- Precision agriculture – cost-effective guidance for tractors and field equipment.
- Drones and UAVs – lightweight, power-efficient correction channel.
- Drone swarms and multi-drone operations – one base station can serve many drones simultaneously, ensuring synchronized, high-precision positioning.
- Autonomous robots and vehicles – dependable local infrastructure for navigation.
In short: RTK + LoRa offers simple, efficient, and scalable centimeter-level positioning for both single devices and coordinated fleets.
- GNSS antenna input with IPEX connector
- LoRa antenna input with IPEX connector
- LoRa configuration switch
- USB and one UART with hardware flow control interface
- Technological MCU programming 6-pin connector
- EVENTA, EVENTB: 3.3V LVTTL, 5V-tolerant, protected, high-impedance external event inputs
- PPS output (3.3V)
- Time pulse LED: Green, Power LED: Purple, PVT LED (GPIO2): Red, RTK LED (GPIO1): Orange
- RxTools Control and Analysis Software
- Extensive visualization and evaluation features
- Dimensions 34x36 mm
- Weight: 10 gr.
- Fully assembled, tested and ready to use
Accessories
AllBand+ 38dB RTK Base station Survey antenna full set with cable and stand.
SKU: ELT0123
AllBand SMA GNSS Embedded Cross Dipole Active GNSS Antenna
SKU: ELT0148
IP65 IPEX (U.FL) to SMA cable, 0.03–0.5 m
SKU: ELT0179-0.03-3
AllBand IPEX Four-star High Precision MultiPatch GNSS antenna
SKU: ELT0193
AllBand Four-star High Precision MultiPatch GNSS antenna set with cable
SKU: ELT0194
AllBand+ Choke Ring 3D High Performance Multiband RTK GNSS Antenna with TNC connector
SKU: ELT0314
AllBand+ GPS, GLONASS, BDS, Galileo 28dB D50xH43 RTK antenna
SKU: ELT0242
AllBand+ GPS, GLONASS, BDS, Galileo 28dB D50xH40 RTK antenna with IPEX cable
SKU: ELT0243
AllBand+ GPS, GLONASS, BDS, Galileo 28dB D50xH40 RTK antenna with SMA cable
SKU: ELT0244-30Product Comparison
| Description |
| Price |
| Vendor |
| Type |
| Product variants |
| mosaic-G5 P6 all-constellation multi-frequency top-performance high precision RTK GNSS receiver with LoRa RTK corrections receiver.mosaic-G5 P6 RTK GNSS with integrated LoRa delivers reliable centimeter-level accuracy, making it ideal for surveying, agriculture, construction, drones, and multi-drone swarms without relying on mobile networks. It tracks all Global Navigation Satellite System (GNSS) constellations and supports all current and future signals. Achieve uncompromising accuracy for your most demanding projects with centimeter-level advanced RTK positioning and Galileo HAS corrections. Built for maximum responsiveness, the system delivers raw measurements with ultra-low latency and an exceptional 100 Hz update rate, while the dual-antenna configuration guarantees highly reliable heading data. To secure your operations in challenging RF environments, the receiver integrates AIM+ Premium—part of the advanced GNSS+ algorithm suite—providing superior protection against signal jamming and spoofing. All of this robust performance is delivered with industry-leading ultra-low power consumption, maximizing your equipment's autonomy in the field. An RTK GNSS receiver with integrated LoRa is ideal for applications where centimeter-level accuracy is required in areas with limited or no internet access. The LoRa link provides a low-power, long-range channel for receiving RTCM corrections directly from a local base station. This makes it especially suitable for:
In short: RTK + LoRa offers simple, efficient, and scalable centimeter-level positioning for both single devices and coordinated fleets.
| Regular price
€549,99
Sale price
€549,99
Regular price
| ELTEHS |
Choose your option
mosaic-G5 P6 RTK with LoRa technology GNSS receiver board
mosaic-G5 P6 RTK with LoRa technology GNSS receiver board
B2B Wholesale pricing available
Register as a wholesale buyer to access special pricing and bulk discounts on many products.
Get B2B ConsultationTax excluded
Available in stock (>10 pcs)
mosaic-G5 P6 all-constellation multi-frequency top-performance high precision RTK GNSS receiver with LoRa RTK corrections receiver.
mosaic-G5 P6 RTK GNSS with integrated LoRa delivers reliable centimeter-level accuracy, making it ideal for surveying, agriculture, construction, drones, and multi-drone swarms without relying on mobile networks. It tracks all Global Navigation Satellite System (GNSS) constellations and supports all current and future signals.
Achieve uncompromising accuracy for your most demanding projects with centimeter-level advanced RTK positioning and Galileo HAS corrections. Built for maximum responsiveness, the system delivers raw measurements with ultra-low latency and an exceptional 100 Hz update rate, while the dual-antenna configuration guarantees highly reliable heading data. To secure your operations in challenging RF environments, the receiver integrates AIM+ Premium—part of the advanced GNSS+ algorithm suite—providing superior protection against signal jamming and spoofing. All of this robust performance is delivered with industry-leading ultra-low power consumption, maximizing your equipment's autonomy in the field.
An RTK GNSS receiver with integrated LoRa is ideal for applications where centimeter-level accuracy is required in areas with limited or no internet access. The LoRa link provides a low-power, long-range channel for receiving RTCM corrections directly from a local base station.
This makes it especially suitable for:
- Surveying and construction – reliable corrections without mobile networks.
- Precision agriculture – cost-effective guidance for tractors and field equipment.
- Drones and UAVs – lightweight, power-efficient correction channel.
- Drone swarms and multi-drone operations – one base station can serve many drones simultaneously, ensuring synchronized, high-precision positioning.
- Autonomous robots and vehicles – dependable local infrastructure for navigation.
In short: RTK + LoRa offers simple, efficient, and scalable centimeter-level positioning for both single devices and coordinated fleets.
- GNSS antenna input with IPEX connector
- LoRa antenna input with IPEX connector
- LoRa configuration switch
- USB and one UART with hardware flow control interface
- Technological MCU programming 6-pin connector
- EVENTA, EVENTB: 3.3V LVTTL, 5V-tolerant, protected, high-impedance external event inputs
- PPS output (3.3V)
- Time pulse LED: Green, Power LED: Purple, PVT LED (GPIO2): Red, RTK LED (GPIO1): Orange
- RxTools Control and Analysis Software
- Extensive visualization and evaluation features
- Dimensions 34x36 mm
- Weight: 10 gr.
- Fully assembled, tested and ready to use
