GPS LEA-M8S GPS breakout board designed for multi GNSS description
The LEA-M8S module delivers concurrent GNSS location capability together with high-performance u-blox M8 positioning technology in the industry proven LEA form factor. With its dual-frequency RF front-end, the LEA-M8S concurrent GNSS module is able to intelligently use the highest number of visible satellites from up to three GNSS systems (GPS/Galileo together with either BeiDou or GLONASS) for more reliable positioning. The LEA-M8S provides exceptional performance with low system power, and is optimized for cost sensitive applications. It also supports message integrity protection, geofencing, and spoofing detection. The LEA-M8S has sophisticated RF-architecture and interference suppression ensuring maximum performance even in GNSS-hostile environments. It features very low power GLONASS functionality. This 6th generation module in the LEA form factor allows simple migration from LEA-6x GPS and LEA-6N GPS /GLONASS modules. The LEA-M8S combines a high level of robustness and integration capability with flexible connectivity options. The DDC (I2C compliant) interface provides connectivity and enables synergies with most u-blox cellular modules. For RF optimization, the LEA-M8S features a front-end SAW filter for increased jamming immunity. LEA-M8S module uses u-blox GNSS chips qualified according to AEC-Q100 and is manufactured in ISO/TS 16949 certified sites. Qualification tests are performed as stipulated in the ISO16750 standard: “Road vehicles – Environmental conditions and testing for electrical and electronic equipment”.
Highlights:
- Seamless upgrade of existing LEA-6 designs to multi-GNSS
- Concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou)
- Active GNSS antenna support
- Receiver type: 72-channel u-blox M8 engine GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1l, Galileo E1 B/C, SBAS L1 C/A: WAAS, EGNOS, MSAS, GAGAN
- Industry leading –167 dBm navigation sensitivity
- Combines low power consumption and high sensitivity
- Superior anti-spoofing and anti-jamming
- UART, USB and I2C compliant interfaces
- u-center u-blox GPS Evaluation Software
- Easy migration from LEA-6 modules
- Dimensions: 38x32 mm
- Weight: 4 gr.
