UM980 GNSS modules

Unicore UM980 GNSS Module – High-Precision Multi-Band RTK L1/L2/L5 GNSS

The Unicore UM980 is a high-performance GNSS module based on the NebulasIV SoC, supporting all major GNSS constellations and multi-frequency bands. It delivers centimeter-level RTK accuracy with fast initialization, making it ideal for professional applications such as surveying, UAV navigation, robotics, and precision agriculture.

Key Features of the Unicore UM980 GNSS Module

• All-Constellation Multi-Band Support: GPS L1/L2/L5, GLONASS L1/L2, Galileo E1/E5a/E5b/E6, BeiDou B1I/B2I/B3I/B1C/B2a/B2b, QZSS L1C/A/L2C/L5/L6, SBAS for reliable positioning worldwide
• High-Performance 1408-Channel Receiver: Powered by NebulasIV SoC for robust signal tracking
• Fast and Reliable RTK Initialization: Accuracy with >99.9% reliability
• High Data Update Rate: Up to 50 Hz for dynamic applications and real-time monitoring
• Compact Form Factor: 17.0 x 22.0 x 2.6 mm LGA package, easy integration into UAVs, robotics, and embedded systems
• Wide Operating Temperature: -40°C to +85°C for industrial-grade performance
• Low Power Consumption: ~480 mW for energy-efficient operation

Applications of the Unicore UM980 GNSS Module

• Surveying and Mapping: High-precision geospatial data collection for construction and topography
• Unmanned Aerial Vehicles (UAVs): Accurate navigation, mapping, and aerial data acquisition
• Robotics and Autonomous Systems: Precise localization for industrial robots and autonomous vehicles
• Precision Agriculture: Field monitoring and automated farming tasks
• Machine Control and Automation: Reliable GNSS positioning for industrial machinery and smart devices

Why Choose Unicore UM980?

With full multi-band and multi-constellation support, fast RTK convergence, high reliability, and low power consumption, the Unicore UM980 GNSS module is the perfect solution for professional high-precision positioning applications.
